The American standard globe valve produced by our company is designed and manufactured in full accordance with the American standard, with beautiful structure and advanced. The opening and closing part of the valve is the valve disc, the flow direction is low into high, the globe valve is fully open and fully closed, and the valve stem is used to operate the valve, and the conical valve disc can do a good job of throttling and cannot play a regulating role. Mainly used in petroleum, chemical, pharmaceutical, fertilizer, power industry and other working conditions of the pipeline, cut off or connect the pipeline medium. The driving mode is manual, gear transmission, electric, pneumatic and so on.
Structural characteristics
1. The technical conditions of manufacturing acceptance shall be stipulated in I Japan thermal power generation valve standard E101;
2. Valve structure length according to E101;
3. The welded groove of the valve body shall be the size provided by the user according to ASME B 16.25;
